PN / USS-SC160A-T-NB-O *
Portable Thermal Imager. Tripod not included.
Main Features:
- 2.8" TFT screen
- Infrared resolution: 160—120
- Frame frequency: 9Hz
- Range of temperature measurement: 30°C~45°C
- Accuracy: ±0.5°C
- Photographed function and SD card storage
- PC software analysis
- Point temperature measurement
- Type-C USB interface for lithium battery charging
- 1/4" tripod mounting hole
Specification:
Sensor: Uncooled focal plane
Temperature range: 30ƒ - 45ƒ
Resolution: 0.1ƒ
Accuracy: ±0.5ƒ @1M
Minimum measuring distance: 15cm
Temperature measurement response time: 500ms (95% of reading)
Thermal imaging pixel: 19200 (160 x 120)
Pixel size: 12mm
Swatch: Black white, red white, blue white, iron red, rainbow
Bandwidth of infrared spectroscopy: 8 - 14mm
Field of view (FOV): 56°(H) x 42°(V)
Instantaneous field of view (IF0V): 6mrad
Thermal imaging sensitivity: < 50mk
Frame rate: <9Hz
Temperature display: Center temperature measurement and high temperature tracking (default)
Image format: BMP
Image modes: Thermal imagery
Temperature measuring point: Besides central point, 3 temperature measuring points can be added
Display resolution: 320 x 240
PC analysis software (PC):
Data communication: Type C USB
Auto power off: Selectable (5min 10min 30min) 30min auto power off (default)
Service time: 6 hours
Charging time: 4 hours
Image storage: Micro SD card
Power: A single Li-ion 3.7V/5000mAh 26650 battery
Display: 2.8" TFT LCD
Product color: Red & grey
Storage temperature: -20-60ƒ (-4-140‰)
Operating temperature: 10-40ƒ (50-104‰)
Working humidity: <90%RH (Non-condensing)
Product size: 236mm x 75.5mm x 86mm
Standard accessories: Manual, Type C USB cable, 16GB TF card
